REDUCES THE RISK OF BIRD STRIKES

Phoenix Airport Wailer Mk V

A Bird Deterrent System That Deters Birds From Airport Runways & Helipads

Using Species Specific Alarm / Distress calls / Cries Of Predators

REDUCES THE RISK OF BIRD STRIKES

Phoenix Airport
Wailer Mk V

A Bird Deterrent System That Deters Birds From Airport Runways & Helipads
Using Species Specific Alarm / Distress calls / Cries Of Predators

Humane & Effective Bird Control

Birds respond to species specific alarm / distress / predator / mechanical sounds. The Phoenix Bird Wailer can be programmed accordingly to humanely deter birds from airports, agricultural areas, tailings ponds, and industrial sites. The Phoenix Bird Wailer should be considered as the core system for any bird dispersal program.

Unique Bird Control System

The Phoenix Airport Bird Wailer Mk V is a state-of-the-art bird deterrent system that permanently modifies roosting behavior of pest birds at runways and helipads. One system protects 2,500’ of runway in addition to a large contiguous area.

The 12V or 110V Phoenix Agritech Mk V Airport Bird Wailer differs from competing systems. It is not a ‘scare’ system relying on loud noises. Instead, creates a "No Fly" zone of rotational, surround sounds at normal dB’s lessening habituation to the ‘same sound / same speaker syndrome. The Wailer operates automatically 24/7 or other programming options.

The Airport Bird Wailer uses high fidelity, natural indigenous species-specific alarm / distress calls, and cries of predators. A wide array of mechanical sounds, shotgun blasts etc. are incorporated in the audio program. The sounds can be clearly heard 1,000’ from each speaker, including the upward pointing speakers. The aimable upward speakers are very effective against soaring birds such as kites and vultures. Electronic sounds (124dBs) are also available and can be heard up to 3,000’.

Click For .pdf Presentation

Phoenix Airport Wailer Presentation

AP Wailer At The Halifax International Airport

FAA Certified Frangible Coupling

Optional LED Light To Indicate the System Is On

Airport Wailer Master Unit Baku Azerbaijan International Airport

Phoenix Airport Wailer Mk V Specifications

System comprises of:-
	1 Master unit with 2 Internal high frequency speakers, plus 2 high volume super-horn speakers attached to master unit, one of which can have a drain hole so it can angled to 45’ for soaring birds (e.g Black Kites, vultures). 4 high volume weatherproof remote super-horn speakers 5 adjustable aluminum stands 4 X 500 FT (152M) shielded cables
System coverage	2500 ft (760M) of runway

Master Unit properties:-
Power Supply	12 VDC 100 micro-amps off line current
Power Supply Option	110v/220v Electronically controlled transformer OR 12v Deep Cycle Battery + 50W Solar-panel + Regulator
Audio Output	Max S.P.L at 500cms (16.5”) up to 124dB(A)
Sound Field Range	Natural sounds .. 1000 ft Electronic sounds .. 3000 ft
Low Frequency Speakers (2)	Weatherproof audio range super-horn speaker 450Hz – 4000Hz
High Frequency Speakers (2)	Piezo electric Horn Tweeter 3500Hz – 27000Hz
Temperature Range	-30^oC to +50^oC
Light Setting	Adjustable for all ambient conditions Automatic night time shutoff, by light sensor or clock Adjustable for night operation only, or 24 hrs
Sound Emission Cycle	Adjustable quiet time between the different sound sequences 2 minutes – 60 minutes
Electronic Sound Blasts	Adjustable 2 – 16 seconds per sound
Volume Controls	4 volume level settings for Electronic and Natural Sound modes separately
Operational Description	The operating program is stored onboard in the Phoenix Wailer's memory , it is pre-programmed to be site-specific for location and species of birds. This program can be changed or added to (e.g a new bird sound) remotely by email link from the program designer. Operates on 12v. The master unit is equipped with two external press buttons and an electronic display which is used to program the following:- Quiet time between sound sequences The system can be ON/OFF function can be controlled by a Light Sensor or a 24 hour clock Presets stored in onboard system memory:- -Selection of Day and/or Night to emit -Variation of sound duration - Electronic and Natural Sound sequences - Electronic Sounds sequences only - Natural Sound sequences only Choice of Sounds (Up to 25 different electronic sounds, plus up to 200+ Natural Sounds can be programmed into the unit). …………………………………………………… The battery power level is displayed (e.g. 88%) Volume Control. There are 4 volume levels for each type of sound. A powerful strobe light can be added to the unit. Sound fidelity: Up to 44 kHz at any volume
Physical Properties:-

Size Master Unit	250 X 190 X 150 mm (9.8” X 7.5” X 5.9”)
Weight	4.53 Kgs (10.00lbs)
Construction	Body: high impact proof fiberglass filled with Polycarbonate IP.65 Lid: high impact proof Polycarbonate IP.65
Master Unit	Consists of an electronic circuit board 2 high frequency speakers 2 low frequency super-horn speakers 2 outlets to connect remote speaker cables
Stands	5 Adjustable stands built of marine grade aluminum. Frangible for 10 lbs + impact
Cables	2 X 152 M (500’) grounded/shielded 4 conductor with weatherproof connectors. 2 X 152 M (500’) grounded/shielded 2 conductor with weatherproof connectors
Speakers	6 Super-horn remote speakers
Optional Extra speakers	4 Super-horn 180^oreverse side speakers
Ground Rod	1 Stainless Steel 760mm (30”)

AP Wailer At The Airport Beirut Lebanon Installation

Remote Speaker Sofia Airport Bulgaria

A System Based On An Exclusive Approach

Most bird aversion systems are designed to startle or 'scare' birds away from target areas. Often the eventually return and the problem continues. The Phoenix Airport Wailer Mk V Bird Deterrent system works differently. This system causes the birds to move away from problem areas slowly - even gradually, actually changing their behavior all together. The result will be a more permanent bird control solution.

The all-new Mk V system carries the randomized program in the onboard memory system. However, using an email link the program can be added to or changed as new sounds become available.

Link to worldwide sound list: https://phoenixagritech.com/sound-list/

Mobile Bird Control For Airports

Retail: $5250.00 + freight. Does not include truck or back-rack.

Call Jack at 703-299-8855
Or fill out this contact form for real help with your pest bird problem.

We need the following information to provide a quotation:

Name *

Email *

Phone *

Name Of Airport *

Physical Address Of Airport *

Address Line 1

Address Line 2

City

State / Province / Region

Postal Code

Country

Google Coordinates *

Length Of Runway *

Target Bird Species *

Brief Description Of Roosting/Nesting Conditions *

Custom Captcha *

Airport Wailer Installations

CANADA:
Hibernia Oil Platform Helipad, Newfoundlans - 1 system, 2013
Grands Prarie Airport, Alberta - 3 systems, 2011
Regina Airport, Saskatchewan - 5 systems, 2007
Quebec City Airport, Quebec - 2 ststems, 2010
CFB Valcartier, Quebec Helipad - 1 system, 2013
Halifax Airport, Nova Scotia - 11 systems, 1993 - 2012
St. John's Airport, Newfoundland - 8 systems, 1998 - 20212
UNITED STATES
San Francisco Airport - 5 systems, 1996
CARIBBEAN
Barbados Airport, Barbados
Grand Cayman Airport, Grand Cayman
GREECE
Tanagra Military Airport - 1 system, 2006
BULGARIA
Sofia Airport
INDIA
Military Airports (testing) - 2010
INDONESIA
Bali International Airport - 8 systems
Baku Airport, Azerbaijan
Astana Airport, Kazakhstan
SINGAPORE
Changi Airport - 2 systems, 2004
BRUNEI
Brunei Airport - 1 system, 2006
HONG KING
Hong Kong Airport - 3 systems, 2010
A2ERBAIJAN
Baku Airport - 6 systems, 2009; 8 systems, 2013
KAZAKHSTAN
Astana Airport
SUDAN
U.N. Mission, Juba Airport - 1 system, 2010
SIERRA LEONE
UN Mission, Freetown, Sierra Leone, Helipad - 1 system, 2011
